Deye SUN-XL20-B Optimiser Concentrator 4 Strings with Rapid Shutdown and PLC IP68
The Deye SUN-XL20-B concentrator is the unit that completes a module-optimiser architecture: it collects the data of the Deye SUN-XL02-B optimisers by PLC over the PV cables and passes it to the monitoring platform, while at the same time enabling the string rapid shutdown function required on site and during maintenance or firefighting operations.
A single unit serves four series strings, works in 1000 V and 1500 V systems with a 12-15 V DC operating voltage and uses MC4 connectors, so it slots into the existing wiring without dedicated data lines. The IP68 housing and the -40/+65 °C range allow permanent field installation, under the modules or close to the string box. It is used with the Deye single-phase and three-phase string inverters on which the SUN-XL02-B optimisers are fitted. CE certified.
Key features
Four strings per unitOne concentrator collects and manages four series strings of optimisers, cutting down the number of devices in the field.
String rapid shutdownTogether with the SUN-XL02-B optimisers it provides rapid shutdown, useful during maintenance and for fire safety.
Platform monitoringIt brings the module-by-module data gathered by the optimisers to the platform, with no extra data cabling.
IP68 from -40 to +65 °CIP68 housing, MC4 connectors and a wide temperature range: permanent outdoor installation, under the modules or at the string box.
Technical specifications
| Feature | Value |
|---|---|
| Product code | SUN-XL20-B |
| Function | concentrator for Deye PV optimisers |
| Connectable strings | 4 series strings |
| Max. system voltage | 1000 V / 1500 V |
| Operating voltage | 12-15 V DC |
| Communication | PLC over the PV cables, no extra data cabling |
| Supported functions | string rapid shutdown and platform monitoring |
| Compatibility | Deye SUN-XL02-B optimisers |
| Connectors | MC4 or MC4-compatible |
| Protection degree | IP68 |
| Operating temperature | -40...+65 °C |
| Dimensions (W×H×D) | 229×109×38 mm |
| Weight | 1600 g |
| Certifications | CE |
Documentation
PDFDatasheet Deye SUN-XL20-BOfficial manufacturer documentInstallation and wiring must be carried out by qualified personnel in accordance with the applicable standards and the electrical design of the system.
