Tigo TS4-A-2F module-level rapid shutdown for 2 modules, 25 A, 1400 W
Tigo TS4-A-2F module-level rapid shutdown for 2 modules, 25 A, 1400 W
Regular price
€58.42
Regular price
Sale price
€58.42
Unit price
per
Tax included.
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: €60 on orders up to €350, free shipping over €350.
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Prices include 22% Italian VAT; the reduced 10% rate covers only goods for photovoltaic and storage systems, with a customer declaration. From abroad: choose 22% VAT, or for 0% VAT place the order by bank transfer without paying and we send you a proforma invoice.
How VAT works ›
How VAT works ›
Delivery in 10-20 days2 modules per unit25 A IscIP68Warranty 25 yearsTigo
Tigo TS4-A-2F module-level rapid shutdown for 2 modules, 25 A, 1400 W
The TS4-A-2F brings module-level rapid shutdown to new and existing systems: a single unit serves two panels, halving the number of devices to install and the cost per module.
When the AC grid is lost, or on command, the string is brought to a safe state in less than 30 seconds. Communication travels along the PV conductors with PLC technology, with no extra wiring. It is sized for high-current modules, with 25 A Isc and 1400 W in total (700 W per input), snaps onto the module frame and is rated IP68.
Key strengths
Two modules per unitHalf the devices to install compared with one unit per module.
Automatic shutdownThe array goes safe when the AC grid is lost.
PLC communicationThe signal travels on the PV cables, with no extra wiring.
25 A IscSuitable for bifacial and high-current modules.
Fast installationSnaps onto the module frame or fixes to the racking.
25-year warrantyCover matching the expected life of the system.
Technical specifications
| Feature | Value |
|---|---|
| Product code | TS4-A-2F |
| Manufacturer | Tigo |
| Modules supported | 2 photovoltaic modules |
| Input power | 1400 W total (700 W per input) |
| Maximum short-circuit current | 25 A per input |
| Maximum current Imp | 20 A per input |
| Maximum input voltage | 80 V per input |
| Operating voltage | 16 - 80 V |
| Maximum efficiency | 99,9 % |
| Communication | PLC over the PV conductors |
| Shutdown time | 30 seconds or less |
| Connectors | MC4 |
| Cable length | Module side 0.12 / 0.2 m, string side 2.2 m |
| Mounting | Snap onto the module frame or fix to the racking |
| Dimensions (W x D x H) | 139,7 x 138,4 x 22,9 mm |
| Weight | 590 g |
| Operating temperature | -40 ~ 80 °C |
| Protection rating | IP68 |
| Maximum altitude | 3000 m |
| Warranty | 25 years |
Documentation
PDFDatasheetTechnical data of the product — TS4-A-2FThe rapid shutdown function also requires the Tigo RSS Transmitter, or an inverter with a built-in Tigo transmitter.
