Victron Lithium NG Battery 12.8V 100Ah 1280Wh LiFePO4 with Integrated Shunt
Victron Lithium NG Battery 12.8V 100Ah 1280Wh LiFePO4 with Integrated Shunt is a Victron Energy storage battery for photovoltaic and off-grid systems. The declared figures are: Chemistry LiFePO4, Protection IP65, Nominal voltage (V) 12.8. Product code: BAT512110620.
The Victron Lithium NG (Next Generation) batteries take the Smart range further: cell voltage and temperature readout and banks up to 385 kWh. 12, 24 and 48 V modules with IP65 protection and bracket or strap mounting. They require an NG BMS.
The battery stores surplus energy and releases it when needed: capacity and voltage must be chosen to match the inverter and the loads.
Key features
Victron part number: BAT512110620Manufacturer's declared figure.
Chemistry: LiFePO4Chemistry of the cells used.
Protection: IP65Manufacturer's declared figure.
Nominal voltage (V): 12.8System voltage the product works at: it must match the rest of the system.
5-year warrantyWarranty as stated by the manufacturer.
Documentation availableThe manufacturer's datasheet is attached as a PDF in the Documentation section.
Technical specifications
| Feature | Value |
|---|---|
| Product code | BAT512110620 |
| Manufacturer | Victron Energy |
| Victron part number | BAT512110620 |
| Chemistry | LiFePO4 |
| Protections | IP65 |
| Nominal voltage (V) | 12.8 |
| Capacity (Ah) | 100 |
| Energy (Wh) | 1280 |
| Max charge/discharge current (A) | 100 (1C) |
| Weight (kg) | 9 |
| Dimensions (mm) | 235 × 197 × 160 |
| Cycle life | 2500 @80% DoD, 3000 @70% DoD, 5000 @50% DoD |
| Terminals | M8 threaded inserts and bolts |
| Warranty | 5 years |
