DC+AC Combiner Box 1000 V with Type 1+2 SPD, 2 Strings on 1 MPPT, 20 A Single-Phase
DC+AC Combiner Box 1000 V with Type 1+2 SPD, 2 Strings on 1 MPPT, 20 A Single-Phase
Regular price
€232.03
Regular price
Sale price
€232.03
Unit price
per
Couldn't load pickup availability
- Prices exclude VAT: tax is calculated in the cart based on the delivery country.
- EU businesses: 0% VAT with a VAT number valid in VIES — the field appears at checkout, below the delivery address.
- Reduced 10% VAT on solar and storage for customers in Italy: write to us before ordering.
AVAILABILITY
Product available, quantity not tracked
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: 60 € per order, with no threshold
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Delivery in 10-20 daysCombiner boxDC+AC sideLitio Store
DC+AC Combiner Box 1000 V with Type 1+2 SPD, 2 Strings on 1 MPPT, 20 A Single-Phase
Combiner box combining the direct current side and the alternating current side for single-phase residential photovoltaic systems. It gathers 2 photovoltaic strings that converge on a single MPPT input of the inverter and simultaneously protects the DC line upstream of the inverter and the AC line downstream, avoiding the installation of two separate boxes.
On the DC side there is a Type 1+2 surge protective device for 1000 V DC, also suitable for buildings equipped with a lightning protection system (LPS), because it discharges both direct lightning current and induced overvoltages. On the AC side there are a Type 1+2 surge arrester and a 20 A single-phase miniature circuit breaker, which isolate and protect the connection line between the inverter and the distribution board. The box is wall-mounted close to the inverter.
Key features
DC and AC protection in a single boxIt gathers in one enclosure the discharge of overvoltages on the string side and the protection of the alternating current line, reducing wiring time and the space taken up.
Type 1+2 SPD on both sidesCombined Type 1+2 arresters are also suitable for buildings with a lightning protection system, where the discharge of direct lightning current is required.
2 strings on 1 MPPTThe two photovoltaic strings are brought in parallel to a single maximum power point tracker of the inverter.
20 A single-phase MCBThe 20 A circuit breaker protects the AC line between the inverter and the main board against overloads and short circuits, and allows it to be isolated.
String voltage up to 1000 VCompatible with the typical open-circuit voltages of the photovoltaic strings of residential inverters up to 1000 V DC.
Compact wall-mount formatCompact size (202 × 201 × 120 mm) and a weight of 1.86 kg for mounting next to the inverter.
Technical specifications
| Feature | Value |
|---|---|
| Switchboard type | Combined DC+AC combiner box for photovoltaic systems |
| System side | Direct current and alternating current |
| Number of PV strings | 2 |
| MPPTs managed | 1 |
| Maximum PV voltage | 1000 V DC |
| DC surge protective device (SPD) | Type 1+2, 1000 V DC |
| AC surge protective device (SPD) | Type 1+2 |
| Miniature circuit breaker (MCB) | 20 A, single-phase (1P) |
| Number of poles / phases | Single-phase AC side |
| Residual current device (RCD) | Not present: to be provided upstream in the distribution board |
| Dimensions (W × H × D) | 202 × 201 × 120 mm |
| Weight | 1.86 kg |
| Reference standards of the components | EN 61643-11 (AC SPDs), EN 61643-31 (PV SPDs), IEC/EN 60898-1 (MCB) |
Installation and wiring must be carried out by qualified personnel in accordance with the applicable standards and the electrical design of the system.
