Deye BOS-B 80.4kWh LiFePO4 256V high voltage rack storage system
Deye BOS-B 80.4kWh LiFePO4 256V high voltage rack storage system
Regular price
€10,447.29
Regular price
Sale price
€10,447.29
Unit price
per
See the price with VAT
Price including VAT by delivery country
- Italy22% €12,745.69
- Germany19% €12,432.27
- France20% €12,536.74
- Austria20% €12,536.74
- Belgium21% €12,641.22
- Bulgaria20% €12,536.74
- Croatia25% €13,059.11
- Cyprus19% €12,432.27
- Czech Republic21% €12,641.22
- Denmark25% €13,059.11
- Estonia24% €12,954.63
- Finland25.5% €13,111.34
- Greece24% €12,954.63
- Hungary27% €13,268.05
- Ireland23% €12,850.16
- Latvia21% €12,641.22
- Lithuania21% €12,641.22
- Luxembourg17% €12,223.32
- Malta18% €12,327.80
- Netherlands21% €12,641.22
- Poland23% €12,850.16
- Portugal23% €12,850.16
- Romania21% €12,641.22
- Slovakia23% €12,850.16
- Slovenia22% €12,745.69
- Spain21% €12,641.22
- Sweden25% €13,059.11
Shown prices exclude VAT. At checkout the rate of the delivery country applies. Businesses with a valid EU VAT number buy without VAT (reverse charge).
Available, quantity not tracked
Couldn't load pickup availability
- Prices exclude VAT: tax is calculated in the cart based on the delivery country.
- EU businesses: 0% VAT with a VAT number valid in VIES — the field appears at checkout, below the delivery address.
- Reduced 10% VAT on solar and storage for customers in Italy: write to us before ordering.
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: 60 € per order, with no threshold
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Kit offer: Buying this kit costs less than buying the same products one by one: there is a single delivery and a lower mark-up. To look at the products in detail and get a tailored quote, visit SolarGear.eu.
Deye BOS-B 80.4kWh LiFePO4 256V high voltage rack storage system
This is not a single part, it is the whole cluster ready to install: 5 BOS-B-Pack16-A3 modules, the Deye BOS-B-PDU-2-A control box with BMS and the Deye BOS-B cabinet under one code. 80.4kWh at 256V, about 72.4kWh usable at 90% depth of discharge. Compared with buying the parts separately, the module count already matches the cabinet and the control box belongs to the same generation: nothing to cross-check, nothing left over or missing. It pairs with Deye high voltage hybrid inverters and PCS units. The series takes from 5 to 16 modules, 80.4 to 257.23kWh, so the system can grow later.
What the system contains
| Component | Qty |
|---|---|
| Deye BOS-B-Pack16-A3 16.08kWh battery module | 5 |
| Deye BOS-B-PDU-2-A control box with BMS | 1 |
| Deye BOS-B cabinet | 1 |
Technical data
| Item | Value |
|---|---|
| Nominal energy | 80.4kWh |
| Usable energy (90% DoD) | 72.4kWh |
| Cluster nominal voltage | 256V |
| Modules in series | 5 |
| Maximum charge and discharge current | 180A |
| Cell chemistry | LiFePO4 cells |
| System weight | 895 kg |
| Shipping | palletised, with a dedicated carrier quoted on the delivery address |
| Warranty | 10 years |
| Product code | SIST-BOSB-80 |
The components are also sold separately: for a different size just change the number of modules, within the minimum and the cabinet capacity. Installation and wiring must be carried out by qualified personnel according to the applicable standards.
