Victron Energy BatteryProtect 12/24V 220A battery disconnect
Victron Energy BatteryProtect 12/24V 220A battery disconnect is a Victron Energy accessory for storage systems and DC installations. The declared figures are: Max continuous current (A) 220, Peak current 600 A (30 s), Operating voltage 6-35 V. Product code: BPR000220400.
The BatteryProtect disconnects the battery from non-essential loads before it is fully discharged (which would damage it) or before it no longer has enough energy to start the engine. It is unidirectional: current flows either to a load or from a battery charger, not both ways.
Accessories of this kind complete the wiring and the protection between battery, inverter and loads.
Key features
Victron part number: BPR000220400Manufacturer's declared figure.
Max continuous current (A): 220Declared current value, to be checked against the protective device and the cable cross-section.
Peak current: 600 A (30 s)Declared current value, to be checked against the protective device and the cable cross-section.
Operating voltage: 6-35 VDeclared voltage value: check it against the limits of the connected equipment.
5-year warrantyWarranty as stated by the manufacturer.
Documentation availableThe manufacturer's datasheet is attached as a PDF in the Documentation section.
Technical specifications
| Feature | Value |
|---|---|
| Product code | BPR000220400 |
| Manufacturer | Victron Energy |
| Victron part number | BPR000220400 |
| Max continuous current (A) | 220 |
| Peak current | 600 A (30 s) |
| Operating voltage | 6-35 V |
| Weight (kg) | 0.8 |
| Dimensions (mm) | 62 × 123 × 120 |
| Consumption | 1.5 mA on, 0.6 mA off |
| Connection | M8 |
| Warranty | 5 years |
