Victron Energy BlueSolar PWM-Light 12/24V 5A PWM solar charge controller
Victron Energy BlueSolar PWM-Light 12/24V 5A PWM solar charge controller is a Victron Energy solar charge controller. The declared figures are: Battery voltage 12/24 V automatic, Charging current (A) 5, Max solar voltage 28 V / 55 V. Product code: SCC010005000.
The BlueSolar PWM-Light charges batteries in three stages and protects them against overload and short circuit: the simple, low-cost solution for small solar systems.
The charge controller matches the panel voltage to the battery voltage and manages charging; MPPT models do so by tracking the maximum power point.
Key features
Victron part number: SCC010005000Manufacturer's declared figure.
Battery voltage: 12/24 V automaticDeclared voltage value: check it against the limits of the connected equipment.
Charge current (A): 5Maximum current allowed during charging.
Max solar voltage: 28 V / 55 VDeclared voltage value: check it against the limits of the connected equipment.
5-year warrantyWarranty as stated by the manufacturer.
Documentation availableThe manufacturer's datasheet is attached as a PDF in the Documentation section.
Technical specifications
| Feature | Value |
|---|---|
| Product code | SCC010005000 |
| Manufacturer | Victron Energy |
| Victron part number | SCC010005000 |
| Battery voltage | 12/24 V automatic |
| Charging current (A) | 5 |
| Max solar voltage | 28 V / 55 V |
| Weight (kg) | 0.15 |
| Dimensions (mm) | 70 × 133 × 33.5 |
| Terminals | 5 mm² / AWG10 |
| Warranty | 5 years |
