Victron Energy EasySolar 12/1600/70-16 MPPT 100/50 inverter charger 12V 1600VA 70A
The EasySolar 12/1600/70-16 MPPT 100/50 is an all-in-one solution: a MultiPlus Compact, an MPPT 100 V / 50 A solar charge controller and a distribution board with RCD and breakers, pre-wired in a single enclosure. A 1600 VA inverter, a 70 A charger and a 16 A transfer switch.
Key strengths
PowerControl
Automatically limits the current drawn from the grid or generator so they are never overloaded: loads come first, battery charging uses whatever is left.
PowerAssist
Adds inverter power to the grid or generator to cover consumption peaks. A 16 A socket can then run far more demanding loads.
UPS function
During a blackout the changeover takes under 20 milliseconds: computers, servers and sensitive equipment keep running without noticing.
4-stage adaptive charging
The adaptive algorithm (bulk, absorption, float, storage) and BatterySafe mode extend lead-acid battery life and are fully compatible with LiFePO4 lithium.
Monitoring and configuration
It is configured and updated with the MK3-USB interface through VictronConnect, or with the VE.Bus Smart dongle over Bluetooth. Connected to a GX device (Cerbo GX, Ekrano GX) it gives full system monitoring locally and remotely on the free VRM portal, with data history, alarms and remote firmware updates.
Technical specifications
Downloadable documentation
PDFEasySolar datasheetOfficial Victron Energy document · download as PDF
