Victron Energy Orion-Tr 24/12-15 non isolato convertitore DC-DC 24V-12V 15A 180W
Victron Energy Orion-Tr 24/12-15 non isolato convertitore DC-DC 24V-12V 15A 180W
Regular price
€36.00
Regular price
Sale price
€36.00
Unit price
per
Couldn't load pickup availability
- Prices exclude VAT: tax is calculated in the cart based on the delivery country.
- EU businesses: 0% VAT with a VAT number valid in VIES — the field appears at checkout, below the delivery address.
- Reduced 10% VAT on solar and storage for customers in Italy: write to us before ordering.
AVAILABILITY
Product available, quantity not tracked
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: 60 € per order, with no threshold
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Delivery in 10-20 days5-year warrantyVictron Energy
Victron Energy Orion-Tr 24/12-15 non-isolated DC-DC converter 24V-12V 15A 180W
Victron Energy Orion-Tr 24/12-15 non-isolated DC-DC converter 24V-12V 15A 180W is a Victron Energy DC-DC converter that matches the DC voltage between two sections of the system. The declared figures are: Power 180 W, Input voltage 18-35 V, Output voltage 12.5 V. Product code: ORI241215200.
Non-isolated Orion-Tr DC-DC converters, 24 → 12 V, compact, from 60 to 240 W. Synchronous rectification takes full-load efficiency above 95 %.
A DC-DC converter takes the DC voltage from the input value up or down to the one the loads need, with or without galvanic isolation.
Key features
Victron part number: ORI241215200Manufacturer's declared figure.
Power: 180 WPower as stated by the manufacturer.
Input voltage: 18-35 VDeclared voltage value: check it against the limits of the connected equipment.
Output voltage: 12.5 VDeclared voltage value: check it against the limits of the connected equipment.
5-year warrantyWarranty as stated by the manufacturer.
Documentation availableThe manufacturer's datasheet is attached as a PDF in the Documentation section.
Technical specifications
| Feature | Value |
|---|---|
| Product code | ORI241215200 |
| Manufacturer | Victron Energy |
| Victron part number | ORI241215200 |
| Power | 180 W |
| Input voltage | 18-35 V |
| Output voltage | 12.5 V |
| Efficiency | 97% |
| Continuous output current | 15 A |
| Maximum output current | 20 A |
| Protection rating | IP43 (with the terminals facing downwards) |
| Bluetooth | No |
| Weight | 0.25 kg |
| Dimensions (H × W × D) | 73 × 94 × 45 mm |
| No-load consumption | <35 mA |
| Galvanic isolation | non-isolated |
| Operating temperature | -20 ÷ +55 °C |
| Warranty | 5 years |
