Victron Energy
Victron Energy Orion-Tr 24/24-17A isolato convertitore DC-DC 24V-24V 400W
Victron Energy Orion-Tr 24/24-17A isolato convertitore DC-DC 24V-24V 400W
Regular price
€193.50
Regular price
Sale price
€193.50
Unit price
per
Couldn't load pickup availability
- Prices exclude VAT: tax is calculated in the cart based on the delivery country.
- EU businesses: 0% VAT with a VAT number valid in VIES — the field appears at checkout, below the delivery address.
- Reduced 10% VAT on solar and storage for customers in Italy: write to us before ordering.
AVAILABILITY
Product available, quantity not tracked
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: 60 € per order, with no threshold
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Delivery in 10-20 days5-year warrantyVictron Energy
Victron Energy Orion-Tr 24/24-17A isolated DC-DC converter 24V-24V 400W
Victron Energy Orion-Tr 24/24-17A isolated DC-DC converter 24V-24V 400W is a Victron Energy DC-DC converter that matches the DC voltage between two sections of the system. The declared figures are: Output voltage tolerance ±0.2 V, Input voltage 16-35 V, Nominal output voltage 24.2 V. Product code: ORI242441110.
The isolated Orion-Tr units are DC-DC converters with a 12, 24 or 48 V input, in the 100, 250 and 400 W power classes. Every model is short-circuit protected, can be used in parallel and has a terminal for remote on/off.
A DC-DC converter takes the DC voltage from the input value up or down to the one the loads need, with or without galvanic isolation.
Key features
Victron part number: ORI242441110Manufacturer's declared figure.
Output voltage tolerance: ±0.2 VDeclared voltage value: check it against the limits of the connected equipment.
Input voltage: 16-35 VDeclared voltage value: check it against the limits of the connected equipment.
Nominal output voltage: 24.2 VDeclared voltage value: check it against the limits of the connected equipment.
5-year warrantyWarranty as stated by the manufacturer.
Documentation availableThe manufacturer's datasheet is attached as a PDF in the Documentation section.
Technical specifications
| Feature | Value |
|---|---|
| Product code | ORI242441110 |
| Manufacturer | Victron Energy |
| Victron part number | ORI242441110 |
| Output voltage tolerance | ±0,2 V |
| Input voltage | 16-35 V |
| Nominal output voltage | 24.2 V |
| Output voltage adjustment | 18-30 V |
| Continuous output current | 17 A |
| Max output current (10 s) | 25 A |
| Continuous power (25 °C) | 480 W |
| Continuous power (40 °C) | 400 W |
| Efficiency | 89% |
| Protection rating | IP43 (with the terminals facing downwards) |
| Bluetooth | No |
| Weight | 1.6 kg |
| Dimensions (H × W × D) | 130 × 186 × 70 mm |
| Output noise | 2 mV rms |
| Consumption (switched off) | <200 µA |
| Max cable cross-section | 6 mm² (110-120 W), 16 mm² (220 W+) |
| Humidity | max. 95% non-condensing |
| Galvanic isolation | 200 V DC |
| Operating temperature | -20 ÷ +55 °C |
| Warranty | 5 years |
