Victron Energy SHS 200 MPPT solar charge controller with 15 DC outputs
Victron Energy SHS 200 MPPT solar charge controller with 15 DC outputs is a Victron Energy solar charge controller. The declared figures are: Battery voltage 12 V, Nominal PV power up to 200 Wp (36-cell panels), Max charging current (A) 14. Product code: SHS121409230.
The SHS 200 is a smart solar charge controller with power distribution for off-grid energy access: a 200 W MPPT with fifteen DC outputs and pay-as-you-go activation.
The charge controller matches the panel voltage to the battery voltage and manages charging; MPPT models do so by tracking the maximum power point.
Key features
Victron part number: SHS121409230Manufacturer's declared figure.
Battery voltage: 12 VDeclared voltage value: check it against the limits of the connected equipment.
Nominal PV power: up to 200 Wp (36-cell panels)Power as stated by the manufacturer.
Max charge current (A): 14Maximum current allowed during charging.
Documentation availableThe manufacturer's datasheet is attached as a PDF in the Documentation section.
Victron EnergyA Victron Energy branded product in the Litio Store catalogue.
Technical specifications
| Feature | Value |
|---|---|
| Product code | SHS121409230 |
| Manufacturer | Victron Energy |
| Victron part number | SHS121409230 |
| Battery voltage | 12 V |
| Nominal PV power | up to 200 Wp (36-cell panels) |
| Max charging current (A) | 14 |
| Max discharge current (A) | 20 |
| Peak efficiency | 96 % |
| Supported battery capacity | up to 160 Ah |
| Load outputs | 15 DC: 1 × 9 A, 2 × 4 A, 2 × 2 A, 10x USB (10 A total) |
| Protections | IP41 |
| Weight (kg) | 0.39 |
| Dimensions (mm) | 148 × 204 × 67 |
| PV connectors | 5.5 × 2.1 mm jack or MC4 |
| Operating temperature | 0-40 °C (derating from 35 °C) |
