Victron Energy trasformatore di isolamento 4500W 115/230V per barche
Victron Energy trasformatore di isolamento 4500W 115/230V per barche
Regular price
€516.60
Regular price
Sale price
€516.60
Unit price
per
Prices exclude VAT: tax is calculated in the cart based on the delivery country.
EU businesses: enter your VAT number at checkout.
AVAILABILITY
Product available, quantity not tracked
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: 60 € per order, with no threshold
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Delivery in 10-20 days5-year warrantyVictron Energy
Victron Energy isolation transformer 4500W 115/230V for boats
Victron Energy isolation transformer 4500W 115/230V for boats is a Victron Energy isolation transformer for galvanic separation from the grid. The declared figures are: Frequency 50/60 Hz, Protection rating IP21, Transformer Toroidal, 1:1.05 ratio. Product code: ITR040452042.
Essential in professional marine installations, the isolation transformer prevents electrolytic corrosion and, above all, makes the electrical system safe. Toroidal technology keeps it quiet and efficient, and the soft start stops the dockside breaker from tripping at switch-on.
An isolation transformer galvanically separates the system from the supply grid, typically in marine and industrial applications.
Key features
Victron part number: ITR040452042Manufacturer's declared figure.
Frequency: 50/60 HzManufacturer's declared figure.
Protection rating: IP21Protection rating against dust and water.
Transformer: Toroidal, 1:1.05 ratioCell form factor.
5-year warrantyWarranty as stated by the manufacturer.
Documentation availableThe manufacturer's datasheet is attached as a PDF in the Documentation section.
Technical specifications
| Feature | Value |
|---|---|
| Product code | ITR040452042 |
| Manufacturer | Victron Energy |
| Victron part number | ITR040452042 |
| Frequency | 50/60 Hz |
| Protection rating | IP21 |
| Transformer | Toroidal, 1:1.05 ratio |
| Rated power | 4500 W |
| Input voltage | 115 or 230 V |
| Maximum current | 38 / 19 A |
| Weight | 22.2 kg |
| Dimensions (H × W × D, mm) | 362 × 258 × 221 |
| Soft start | Yes |
| Warranty | 5 years |
