Victron Energy Venus GX communication hub
Victron Energy Venus GX communication hub is a Victron Energy data logger that collects the system data and sends it on. The declared figures are: Supply voltage 8 - 70 VDC. Product code: BPP900400100.
The Venus GX is the communication hub of the system: it talks to every component and lets you monitor and adjust the system from a smartphone through the free VRM portal.
The data logger collects data from the devices and makes it available to the monitoring portal.
Key features
Victron part number: BPP900400100Manufacturer's declared figure.
Supply voltage: 8 - 70 VDCDeclared voltage value: check it against the limits of the connected equipment.
Current draw: 210 mA @ 12 V, 110 mA @ 24 V, 60 mA @ 48 VManufacturer's declared figure.
5-year warrantyWarranty as stated by the manufacturer.
Documentation availableThe manufacturer's datasheet is attached as a PDF in the Documentation section.
Victron EnergyA Victron Energy branded product in the Litio Store catalogue.
Technical specifications
| Feature | Value |
|---|---|
| Product code | BPP900400100 |
| Manufacturer | Victron Energy |
| Victron part number | BPP900400100 |
| Supply voltage | 8 - 70 VDC |
| Dimensions (H × W × D, mm) | 45 × 143 × 96 |
| Absorption | 210 mA @ 12 V, 110 mA @ 24 V, 60 mA @ 48 V |
| VE.Direct ports | 2 isolated ports |
| VE.Can | 2 RJ45 in parallel, isolated |
| Second CAN port | Non-isolated |
| VE.Bus ports | 2 RJ45 in parallel, isolated |
| USB | 2 host ports, non-isolated |
| Ethernet | 10/100/1000 Mb RJ45, isolated except for the shield |
| WiFi | Access point and client |
| Tank inputs | 3, configurable EU (0 - 180 Ohm) or US (240 - 30 Ohm) |
| Temperature inputs | 2 (requires ASS000001000) |
| Relay | NO/COM/NC, 6 A 250 VAC / 30 VDC |
| Operating temperature | -20 ÷ +50 °C |
| Warranty | 5 years |
