SolarEdge Site Power Controller SE2000-PFSV-MSDC-4BPC
The SolarEdge Site Power Controller SE2000-PFSV-MSDC-4BPC is the site controller that dynamically manages site power, acting on both active power and reactive power. It is the right device for commercial and industrial plants that have to comply with grid operator requirements, export limitation or centralised control logic.
It offers 4 analogue input channels configurable for voltage or current (10-bit resolution, +/-0.1 % accuracy at 25 °C), 8 digital inputs and 8 digital outputs and a rich set of interfaces: RS485, RS232, USB, Ethernet RJ45 10/100 Mbps, built-in UMTS/HSPA modem, ZigBee Pro and LoRa 868 MHz radios. It is powered at 9-60 V DC (12, 24 or 48 V DC nominal), weighs less than 200 g and can be mounted on a DIN rail, on the wall or on a bracket. Operating temperature from -10 to +75 °C and 2-year warranty.
Key features
Dynamic power controlRegulates the active and reactive power of the plant in real time.
4 analogue inputsChannels configurable for voltage or current, 10-bit resolution and +/-0.1 % accuracy at 25 °C.
8 digital inputs and 8 outputsBroad interfacing with sensors, contacts and plant control logic.
Complete interfacesRS485, RS232, USB, Ethernet 10/100 Mbps, UMTS/HSPA modem, ZigBee Pro and LoRa 868 MHz.
Flexible installationDIN rail, wall or bracket mounting; weight below 200 g.
Wide temperature rangeOperation from -10 to +75 °C with relative humidity from 5 to 95 %.
Technical specifications
| Feature | Value |
|---|---|
| Product code | SE2000-PFSV-MSDC-4BPC |
| Model | SolarEdge Site Power Controller SE2000-PFSV-MSDC-4BPC |
| Function | Dynamic site power control (active and reactive power) |
| Analogue inputs | 4 channels configurable for voltage or current |
| Resolution / accuracy | 10 bit, +/-0.1 % at 25 °C |
| Digital inputs | 8 |
| Digital outputs | 8 |
| Interfaces | RS485, RS232, USB, Ethernet RJ45 10/100 Mbps, UMTS/HSPA modem, ZigBee Pro, LoRa 868 MHz |
| Power supply | 9-60 V DC (nominal 12, 24, 48 V DC) |
| Mounting | DIN rail, wall or support bracket |
| Dimensions | 170 x 165 x 61 mm |
| Weight | < 200 g |
| Operating temperature | -10 °C ... +75 °C |
| Storage temperature | -40 °C ... +85 °C |
| Relative humidity | 5-95 % |
| Standards | EN 55022, EN 61000 series, RoHS, WEEE |
| Warranty | 2 years |
Documentation
PDFDatasheet SE2000-PFSV-MSDC-4BPCOfficial manufacturer documentPlease check compatibility with your inverter model before ordering.
