Fronius 7.08 kWp Solar Kit with 6.3–9.45 kWh Battery – 6 kW Three-Phase Hybrid Inverter
Complete home system: generation, storage and smart energy management
🚚 Fast delivery in 10–20 days.
Residential Solar Kit with Battery Storage
Residential kit with battery storage for self-consumption, grid-tied operation and backup power depending on the installation, built around the Fronius Symo GEN24 6.0 Plus inverter.
| ☀️ 7.08 kWp Solar | 🔋 6.3–9.45 kWh Storage | ⚡ 6 kW Inverter | 🔌 Three-Phase Hybrid |
Kit Contents
12× 590 W N-Type TOPCon bifacial dual-glass solar modules
Total array power 7.08 kWp. Vmp 44.35 V, Voc 52.82 V, Imp 13.30 A, Isc 14.02 A, size 2278 × 1134 × 30 mm.
1× Fronius Symo GEN24 6.0 Plus 6 kW three-phase hybrid inverter
Manages PV generation, battery charging and discharging and grid exchange. MPPT1 25 A (2 strings), MPPT2 12.5 A; 174–800 V.
1× Fronius Smart Meter TS 65A-3 three-phase
Measures grid import/export: required for self-consumption, battery management and export limitation.
1× Selectable storage: Fronius Reserva
6.3 kWh: 1× Fronius Reserva BMS + base, 2× Fronius Reserva 3.15 kWh module or 9.45 kWh: 1× Fronius Reserva BMS + base, 3× Fronius Reserva 3.15 kWh module.
1× Three-phase AC field box 20 A with MCB, 300 mA Type A RCD and Type 2 SPD
Protection and isolation of the AC grid connection.
1× DC field box 1000 V for 1 string with Type 2 SPD and Stäubli MC4 connectors
Surge protection of the PV strings on the DC side; DC isolation is built into the inverter.
PV String Design
1 string of 12 modules. Operating voltage Vmp 532.2 V, Voc at 25 °C 633.8 V, worst-case Voc at −25 °C 723 V (conservative coefficient −0.28 %/°C) — within the inverter’s 1000 V limit and the 1000 V rating of the protection boxes. Maximum current per MPPT 13.3 A, within the input limit (MPPT1 25 A (2 strings), MPPT2 12.5 A; 174–800 V). DC/AC ratio 1.18×.
Storage, Grid and Operation
Fronius Reserva is compatible with the Symo GEN24 Plus: 2 to 5 modules per tower, with the BMS + base included. The included Smart Meter TS enables self-consumption and export limitation. The second MPPT stays free for later expansion. Power within 11.08 kW: interface protection is the one built into the inverter.
A consistent, well-engineered system
The kit uses selected components and a PV configuration calculated and checked against the inverter’s electrical limits, ready for installation by qualified personnel. The product includes only the listed components. Mounting structures, cables, connectors, installation, permits, commissioning and any additional protection required by the design or lightning-risk assessment are not included. Shipping is a flat €120 in Italy and €350 within the European Union.
