Felicity FLS48100SCG1 Low-Voltage BMS Base for FLS48100SMG1 Modules
Felicity FLS48100SCG1 Low-Voltage BMS Base for FLS48100SMG1 Modules
Regular price
€640.09
Regular price
Sale price
€640.09
Unit price
per
Tax included.
AVAILABILITY
Product available, quantity not tracked
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: €60 on orders up to €350, free shipping over €350.
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Prices shown include 22% Italian VAT. The 10% rate applies only to goods for photovoltaic and storage systems, with a declaration from the customer. From outside Italy: pick 22% VAT, or for 0% VAT place the order by bank transfer without paying and we will send a proforma invoice.
How VAT works ›
How VAT works ›
Delivery in 10-20 daysFelicity Solar
Felicity FLS48100SCG1 Low-Voltage BMS Base for FLS48100SMG1 Modules
A battery tower without its control unit is just a pile of modules: the FLS48100SCG1 is what measures cell by cell, balances, opens and closes the contactor and tells the inverter what is going on. One per cluster.
It closes the group of FLS48100SMG1 modules at 51.2 V and acts as the base of the stack: the BMS sits at the bottom, the modules pile on top. This is what you need when the hybrid inverter works at low voltage, which covers the large majority of residential systems.
It communicates over CAN and RS485, has its own screen and is followed from the app. Ten-year manufacturer warranty. We ship within Italy and across the European Union.
At a glance
Part number: FLS48100SCG1Genuine Felicity Solar product with the manufacturer's warranty.
Manufacturer: Felicity SolarGenuine Felicity Solar product with the manufacturer's warranty.
Model: FLS48100SCG1Genuine Felicity Solar product with the manufacturer's warranty.
Measurement type: Control unit with BMSGenuine Felicity Solar product with the manufacturer's warranty.
Nominal voltage: 51.2 V per moduleGenuine Felicity Solar product with the manufacturer's warranty.
Technical data
| Specification | Value |
|---|---|
| Part number | FLS48100SCG1 |
| Manufacturer | Felicity Solar |
| Model | FLS48100SCG1 |
| Measurement type | Control unit with BMS |
| Nominal voltage | 51.2 V per module |
| Expansion | 5 to 16 FLS48100SMG1 modules |
| Nominal energy | 25.6 to 81.92 kWh per cluster |
| Charge and discharge current | 50 A nominal, 100 A maximum |
| Protection rating | IP21 |
| Communication | CAN, RS485, screen and app |
| Mounting | Floor stacking |
| Warranty | 10 years |
