Dyness Stack280 14.34kWh 280Ah High Voltage LiFePO4 Battery Module

Dyness Stack280 14.34kWh 280Ah High Voltage LiFePO4 Battery Module

€1,882.60
€1,882.60
Sale Sold out Excl. VAT — calculated in the cart131 €/kWh
See the price with VAT

Price including VAT by delivery country

  • Italy22% €2,296.77
  • Germany19% €2,240.29
  • France20% €2,259.12
  • Austria20% €2,259.12
  • Belgium21% €2,277.94
  • Bulgaria20% €2,259.12
  • Croatia25% €2,353.25
  • Cyprus19% €2,240.29
  • Czech Republic21% €2,277.94
  • Denmark25% €2,353.25
  • Estonia24% €2,334.42
  • Finland25.5% €2,362.66
  • Greece24% €2,334.42
  • Hungary27% €2,390.90
  • Ireland23% €2,315.59
  • Latvia21% €2,277.94
  • Lithuania21% €2,277.94
  • Luxembourg17% €2,202.64
  • Malta18% €2,221.46
  • Netherlands21% €2,277.94
  • Poland23% €2,315.59
  • Portugal23% €2,315.59
  • Romania21% €2,277.94
  • Slovakia23% €2,315.59
  • Slovenia22% €2,296.77
  • Spain21% €2,277.94
  • Sweden25% €2,353.25

Shown prices exclude VAT. At checkout the rate of the delivery country applies. Businesses with a valid EU VAT number buy without VAT (reverse charge).

  • Prices exclude VAT: tax is calculated in the cart based on the delivery country.
  • EU businesses: 0% VAT with a VAT number valid in VIES — the field appears at checkout, below the delivery address.
  • Reduced 10% VAT on solar and storage for customers in Italy: write to us before ordering.

AVAILABILITY

222 units in stock at our supplier

Shipping

  • Italy: €13 on orders up to €150, free shipping over €150.
  • European Union: 60 € per order, with no threshold

Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.

Read the full shipping conditions

View full details
Delivery in 10-20 daysDyness

Dyness Stack280 14.34kWh 280Ah High Voltage LiFePO4 Battery Module

The Dyness Stack280 is the 14.34kWh module of the Stack280 stackable storage system, built for commercial and industrial sites and equally at home where domestic consumption runs high. Each module holds 280Ah at 51.2V: one unit does the work of almost three 5kWh batteries, with a single connection to make.

Modules stack into clusters in series, and a system starts at 43kWh — three modules. Connecting up to 12 clusters in parallel takes capacity to 215kWh. Continuous discharge is 7168W, rising to a 10240W peak, with charge and discharge current up to 200A: enough for machinery and industrial loads, not only domestic self-consumption.

Safety is the defining feature: inside the module an aerosol fire suppression system detects and smothers an incipient fire within 5 seconds, while forced air cooling keeps cell temperature in check under load. The LiFePO4 cells are designed for more than 8000 cycles at a 95% depth of discharge. The module weighs 110kg, so handling needs planning. Installation and commissioning must be carried out by qualified personnel.

Key strengths

14.34kWh per module280Ah at 51.2V with a 95% depth of discharge.
43 to 215kWhStackable clusters, up to 12 clusters in parallel.
Up to 200A7168W continuous and a 10240W peak, charging and discharging.
Suppression in 5 secondsBuilt-in aerosol system and forced air cooling.
Over 8000 cyclesLiFePO4 cells for systems that work every day.

Technical specifications

Feature Value
Product code DY-STACK280
Manufacturer Dyness
Series Stack280
Chemistry LiFePO4 (lithium iron phosphate)
Nominal energy 14.34kWh (14336Wh)
Module nominal voltage 51.2V
Nominal capacity 280Ah
Depth of discharge (DoD) 95%
Continuous discharge power 7168W
Maximum discharge power (5 minutes) 10240W
Maximum charge power (5 minutes) 10240W
Maximum charge and discharge current 200A
System capacity 43 to 215kWh (up to 12 clusters in parallel)
Safety Aerosol fire suppression, acting within 5 seconds
Cooling Forced air
Cycle life Over 8000
Weight 110kg
PDFManufacturer datasheetPDF document
