SolaX SCT-36 split-core current transformer 400 A/40 mA
SolaX SCT-36 split-core current transformer 400 A/40 mA
Regular price
€68.90
Regular price
Sale price
€68.90
Unit price
per
Tax included.
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: €60 on orders up to €350, free shipping over €350.
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Prices include 22% Italian VAT; the reduced 10% rate covers only goods for photovoltaic and storage systems, with a customer declaration. From abroad: choose 22% VAT, or for 0% VAT place the order by bank transfer without paying and we send you a proforma invoice.
How VAT works ›
How VAT works ›
Delivery in 10-20 days400 A / 40 mASplit-coreClass 0.5SolaX
SolaX SCT-36 split-core current transformer 400 A/40 mA
The SCT-36 is the 400 A current transformer for systems where the current at the connection point exceeds that of residential CTs: small businesses, sheds and apartment blocks with a SolaX inverter and a three-phase meter.
It is split-core, so it fits cables already in place without breaking the power circuit. Inner diameter 32.5 mm, 40 mA output with a 10000:1 ratio and class 0.5 accuracy, 2 m secondary leads.
Key strengths
400 A primary currentFor connection points beyond the reach of residential CTs.
Split-coreFits cables already installed without breaking the circuit.
32.5 mm inner diameterTakes large cross-section cables too.
Class 0.5Accuracy suited to self-consumption control.
40 mA outputCompatible with SolaX M3-40 and M3-40-Dual meters.
2 m leadEnough to reach the board holding the meter.
Technical specifications
| Feature | Value |
|---|---|
| Product code | SCT-36 |
| Manufacturer | SolaX |
| Type | Split-core current transformer |
| Input | 400 A |
| Output | 40 mA (AC) |
| Transformation ratio | 10000 : 1 |
| Accuracy class | Class 0.5 |
| Inner diameter | 32,5 mm |
| Frequency | 50 / 60 Hz |
| Compatibility | SolaX M3-40, M3-40-Dual meters and XHub |
| Cable length | 2 m |
| Operating temperature | -40 ~ 70 °C |
| Maximum altitude | Up to 4000 m |
| Certifications | CE, UL, RoHS, REACH |
Documentation
PDFDatasheetTechnical data of the product — SCT-36Three-phase systems need three current transformers, one per phase.
