• Bancale da 36 moduli fotovoltaici Trina Vertex S+ 465 W doppio vetro cornice nera
1 1

Trina Solar

Pallet of 36 Trina Vertex S+ 465 W i-TOPCon dual glass Black Frame PV modules 16.7 kW

Pallet of 36 Trina Vertex S+ 465 W i-TOPCon dual glass Black Frame PV modules 16.7 kW

€3,572.79
€3,572.79
Sale Sold out
Tax included.

SOLAR PANEL SHIPPING

  • Italy: 120 €
  • European Union: 350 €

Dedicated rate: modules, pallets and kits with panels ship on a pallet with a specialised carrier. Free shipping over €150 does not apply here. The exact amount is confirmed at checkout; for non-EU countries please ask for a quote.

Read the full shipping conditions

VAT rate
View full details
VAT notice
Companies and foreign private customers: purchase with 22% VAT. The 10% VAT rate is reserved for private customers resident in Italy only — find out more.
Foreign companies entitled to 0% VAT: write to info@litio.store.

Delivery in 10-20 days.

Shipping costs
Italy: 120 €. European Union: 350 €.

No minimum order quantity. Fixed shipping: 120 €.

Pallet of 36 Trina Vertex S+ 465 W i-TOPCon double-glass Black Frame photovoltaic modules 16,7 kW

Complete pallet of 36 Trina Solar Vertex S+ modules of 465 W, for a total power of 16,74 kWp. Tier-1 monocrystalline modules with N-Type i-TOPCon cells and double-glass 1,6/1,6 mm construction, power density of about 227 W/m².

The low degradation (1% in the first year, then 0,4% per year) ensures more energy over time than conventional P-Type modules. Suitable for residential, commercial and industrial roofs.

  • Pallet composition: 36 modules
  • Total power: 16,74 kWp
  • Manufacturer: Trina Solar — Vertex S+ series (TSM-465-NEG9R.28)
  • STC power per module: 465 Wp
  • Vmp / Imp: 45,8 V / 10,20 A
  • Voc / Isc: 54,2 V / 10,85 A
  • Efficiency: 23,3%
  • Maximum system voltage: 1500 VDC
  • Maximum fuse: 25 A
  • Cells: 144 N-Type i-TOPCon monocrystalline
  • Glass: 1,6 mm tempered double glass
  • Frame: Black Frame
  • Protection: IP68 — IP67/IP68 junction box with 3 diodes
  • Connectors: MC4 or compatible — 30 cm cables, 4 mm²
  • Maximum load: 5400 Pa snow / 2400 Pa wind
  • Power temperature coefficient: -0,29 %/°C
  • Operating temperature: -40 / +70 °C
  • Fire reaction class: Class 1/A
  • Module dimensions: 1762 × 1134 × 30 mm
  • Warranty: 25 years product and 30 years performance (87,4%)
  • Product code: TSM-465-NEG9R.28-MC4-EVO2

Series or parallel connection must respect the voltage and current limits of the inverter's MPPTs and the electrical design of the system.
