SolarEdge S440-1GM4MRM power optimizer 440 W for 1 photovoltaic module
SolarEdge S440-1GM4MRM power optimizer 440 W for 1 photovoltaic module
Regular price
€59.99
Regular price
Sale price
€59.99
Unit price
per
Tax included.
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: €60 on orders up to €350, free shipping over €350.
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Prices include 22% Italian VAT; the reduced 10% rate covers only goods for photovoltaic and storage systems, with a customer declaration. From abroad: choose 22% VAT, or for 0% VAT place the order by bank transfer without paying and we send you a proforma invoice.
How VAT works ›
How VAT works ›
Delivery in 10-20 days440 W99.5 % efficiencyIP68Warranty 25 yearsSolarEdge
SolarEdge S440-1GM4MRM power optimizer 440 W for 1 photovoltaic module
The SolarEdge S440-1GM4MRM power optimizer works on one module and tracks its maximum power point independently of the others: a shaded roof plane, a dirty panel or a manufacturing tolerance no longer penalises the whole string.
It is part of the SolarEdge system: together with the inverter it provides module-level shutdown, with the voltage dropping to 1 V per optimizer when the grid is lost, protecting installers and firefighters. Maximum efficiency 99.5 %, MC4 connectors, IP68 rating and a 25-year warranty.
Key strengths
Every module at its bestIndependent MPPT per module: shade and dirt do not drag the string down.
99.5 % efficiencyMinimal conversion losses along the DC path.
Module-level shutdownWith no grid the voltage drops to 1 V per optimizer.
Bifacial compatibleDesigned for high-current modules as well.
Strings of different lengthsAllows roof planes with different orientations and module counts.
25-year warrantyThe same expected life as the PV system.
Technical specifications
| Feature | Value |
|---|---|
| Product code | S440-1GM4MRM |
| Manufacturer | SolarEdge |
| Input power | 440 W per module |
| Modules supported | 1 photovoltaic module |
| Maximum input voltage (Voc) | 60 Vdc |
| MPPT voltage | 8 - 60 Vdc |
| Maximum short-circuit current | 14,5 A |
| Maximum efficiency | 99,5 % |
| Weighted efficiency | 98,6 % |
| Maximum output current | 15 Adc |
| Safety output voltage in standby | 1 Vdc per optimizer |
| Maximum system voltage | 1000 Vdc |
| Connectors | MC4 input and output |
| Cable length | Input 0.1 m; output 2.3 m (+) and 0.1 m (-) |
| Dimensions (W x D x H) | 129 x 155 x 30 mm |
| Weight | 655 g |
| Operating temperature | -40 ~ 85 °C |
| Protection rating | IP68 / NEMA 6P |
| Warranty | 25 years |
Documentation
PDFDatasheetTechnical data of the product — S440-1GM4MRMSolarEdge optimizers only work with SolarEdge inverters: check the datasheet for the minimum and maximum number of optimizers per string.
