Daze Dazebox Home S 22.2 kW three-phase 32 A EV Wallbox, Type 2 socket, bring your own cable — IP55 IK10, Wi-Fi and Bluetooth
Daze Dazebox Home S 22.2 kW three-phase 32 A EV Wallbox, Type 2 socket, bring your own cable — IP55 IK10, Wi-Fi and Bluetooth
Regular price
€917.41
Regular price
Sale price
€917.41
Unit price
per
Tax included.
AVAILABILITY
30 units in stock at our supplier
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: €60 on orders up to €350, free shipping over €350.
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Prices shown include 22% Italian VAT. The 10% rate applies only to goods for photovoltaic and storage systems, with a declaration from the customer. From outside Italy: pick 22% VAT, or for 0% VAT place the order by bank transfer without paying and we will send a proforma invoice.
How VAT works ›
How VAT works ›
Delivery in 10-20 daysDaze
Daze Dazebox Home S 22.2 kW three-phase 32 A EV Wallbox, Type 2 socket, bring your own cable — IP55 IK10, Wi-Fi and Bluetooth
The Dazebox Home S is the three-phase 22.2 kW version: 32 A, Type 2 socket, bring your own cable. Power is not fixed — it adjusts from 4.2 kW up to the maximum, so the same wallbox suits a domestic meter as well as a larger supply without tripping anything.
It connects over Wi-Fi, Bluetooth or Ethernet and speaks OCPP 1.6 JSON, so it is not locked inside a single app. It does load balancing across up to eight charging points and has a solar-only mode: it charges the car with your PV surplus instead of exporting it for next to nothing. Charging can be scheduled by time band. Three RFID cards are included to authorise charging.
Built for outdoors: IP55 and IK10, operating temperature −30 to +55 °C, wall mounting or on the Daze floor stand. 200 × 356 × 110 mm without the cable, about 5 kg. Mode 3 to IEC 61851, with built-in shunt trip coil.
At a glance
Product code: DS01IT32TDaze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Model: Daze Dazebox Home SDaze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Maximum power: 22,2 kWDaze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Adjustable power: from 4.2 kW to maximumDaze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Phase and current: three-phase, 32 A (adjustable from 6.5 A)Daze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Technical data
| Specification | Value |
|---|---|
| Product code | DS01IT32T |
| Model | Daze Dazebox Home S |
| Maximum power | 22,2 kW |
| Adjustable power | from 4.2 kW to maximum |
| Phase and current | three-phase, 32 A (adjustable from 6.5 A) |
| Vehicle connection | Type 2 socket, bring your own cable |
| Charging mode | Modo 3 (IEC 61851) |
| Connectivity | Wi-Fi, Bluetooth, 1 Ethernet port |
| Protocol | OCPP 1.6 JSON |
| Authorisation | RFID reader, 3 cards included |
| Power management | load balancing across up to 8 charging points, solar-only mode, time-band scheduling |
| Display | no, status via LED and app |
| Protection rating | IP55, IK10 |
| Operating temperature | −30 … +55 °C |
| Dimensions and weight | 200 × 356 × 110 mm (without cable), about 5 kg |
| Installation | wall or floor stand |
| Manufacturer | Daze, Vicenza (Italia) |
