Daze Dazebox Home T 22.2 kW three-phase 32 A EV Wallbox, integrated 5 m Type 2 cable — IP55 IK10, Wi-Fi and Bluetooth
Daze Dazebox Home T 22.2 kW three-phase 32 A EV Wallbox, integrated 5 m Type 2 cable — IP55 IK10, Wi-Fi and Bluetooth
Regular price
€955.78
Regular price
Sale price
€955.78
Unit price
per
Tax included.
AVAILABILITY
32 units in stock at our supplier
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: €60 on orders up to €350, free shipping over €350.
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Prices shown include 22% Italian VAT. The 10% rate applies only to goods for photovoltaic and storage systems, with a declaration from the customer. From outside Italy: pick 22% VAT, or for 0% VAT place the order by bank transfer without paying and we will send a proforma invoice.
How VAT works ›
How VAT works ›
Delivery in 10-20 daysDaze
Daze Dazebox Home T 22.2 kW three-phase 32 A EV Wallbox, integrated 5 m Type 2 cable — IP55 IK10, Wi-Fi and Bluetooth
The Dazebox Home T is the three-phase 22.2 kW version: 32 A, integrated 5 m Type 2 cable. Power is not fixed — it adjusts from 4.2 kW up to the maximum, so the same wallbox suits a domestic meter as well as a larger supply without tripping anything.
It connects over Wi-Fi, Bluetooth or Ethernet and speaks OCPP 1.6 JSON, so it is not locked inside a single app. It does load balancing across up to eight charging points and has a solar-only mode: it charges the car with your PV surplus instead of exporting it for next to nothing. Charging can be scheduled by time band. The built-in screen shows power, energy delivered and session status, and three RFID cards are included.
Built for outdoors: IP55 and IK10, operating temperature −30 to +55 °C, wall mounting or on the Daze floor stand. 200 × 356 × 110 mm without the cable, about 5 kg. Mode 3 to IEC 61851, with built-in shunt trip coil.
At a glance
Product code: DT01IT32T5Daze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Model: Daze Dazebox Home TDaze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Maximum power: 22,2 kWDaze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Adjustable power: from 4.2 kW to maximumDaze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Phase and current: three-phase, 32 A (adjustable from 6.5 A)Daze is an Italian manufacturer from Vicenza specialising in electric vehicle charging: it designs and assembles in Italy, with support and spare parts that do not come from the other side of the world.
Technical data
| Specification | Value |
|---|---|
| Product code | DT01IT32T5 |
| Model | Daze Dazebox Home T |
| Maximum power | 22,2 kW |
| Adjustable power | from 4.2 kW to maximum |
| Phase and current | three-phase, 32 A (adjustable from 6.5 A) |
| Vehicle connection | integrated 5 m Type 2 cable |
| Charging mode | Modo 3 (IEC 61851) |
| Connectivity | Wi-Fi, Bluetooth, 1 Ethernet port |
| Protocol | OCPP 1.6 JSON |
| Authorisation | RFID reader, 3 cards included |
| Power management | load balancing across up to 8 charging points, solar-only mode, time-band scheduling |
| Display | yes, built in |
| Protection rating | IP55, IK10 |
| Operating temperature | −30 … +55 °C |
| Dimensions and weight | 200 × 356 × 110 mm (without cable), about 5 kg |
| Installation | wall or floor stand |
| Manufacturer | Daze, Vicenza (Italia) |
