SolaX
SolaX XHub energy manager for PV, storage, EV chargers and heat pumps
SolaX XHub energy manager for PV, storage, EV chargers and heat pumps
Regular price
€352.45
Regular price
Sale price
€352.45
Unit price
per
Tax included.
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: €60 on orders up to €350, free shipping over €350.
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Prices include 22% Italian VAT; the reduced 10% rate covers only goods for photovoltaic and storage systems, with a customer declaration. From abroad: choose 22% VAT, or for 0% VAT place the order by bank transfer without paying and we send you a proforma invoice.
How VAT works ›
How VAT works ›
Delivery in 10-20 daysAI-based managementDIN railRS485 and Wi-FiSolaX
SolaX XHub energy manager for PV, storage, EV chargers and heat pumps
The XHub is the brain of the system: it puts PV production, the battery, the EV charger, the heat pump and the household loads under a single controller that decides who gets power and in which order.
SolaX's forecasting algorithms estimate generation and consumption and move high-power loads to where they pay off; ahead of a storm or a grid outage the system can pre-charge the battery. It mounts on a DIN rail and talks to the rest of the system over RS485, Wi-Fi, Bluetooth and Ethernet, with 4 digital inputs and 4 digital outputs for load control.
Key strengths
A single coordinatorPV, storage, EV charger, heat pump and household loads managed together.
Load priorityHigh-power loads are switched on in the order you set.
AI forecastingEstimates generation and consumption and adapts the strategy day by day.
Pre-charge before outagesThe battery can be charged in advance of bad weather or a grid outage.
Open to third partiesWorks with EEBUS, SG Ready, Modbus and Shelly devices.
Grid complianceSupports ripple control, DRM and export limitation.
Technical specifications
| Feature | Value |
|---|---|
| Product code | XHub |
| Manufacturer | SolaX |
| Power supply | 100~240 V, 50/60 Hz (single-phase 1P2W and three-phase 3P4W) |
| Power consumption | 5 W typical, 8 W peak |
| Communication | LAN and Ethernet 10/100 Mbps, Wi-Fi 802.11 b/g/n, Bluetooth BLE 5.1, 2 x RS485 |
| Input | 4 digital inputs and 2 analogue inputs |
| Output | 4 digital outputs |
| Measurable current | Up to 80 A direct, above 80 A with an external CT |
| Accuracy class | Energy accuracy ±1 % |
| Compatibility | SolaX Cloud app and portal |
| Mounting | DIN rail |
| Protection rating | IP20 |
| Operating temperature | -20 ~ 60 °C |
| Operating humidity | 5 ~ 95 % non-condensing |
| Maximum altitude | 3000 m |
| Dimensions (W x D x H) | 126 x 100 x 65 mm |
| Weight | 600 g |
| Certifications | CE, RCM, PSTI |
Documentation
PDFDatasheetTechnical data of the product — XHubMeasuring above 80 A requires SolaX current transformers, sold separately.
