Solplanet ASW3K-LT-G2 Pro String Inverter 3 kW Three-phase 2 MPPT
The ASW3K-LT-G2 Pro is a three-phase string inverter rated 3 kW from Solplanet, AISWEI's PV brand. It accepts up to 4500 Wp of array on 2 MPP trackers, with 1100 V maximum DC voltage and a 150-1000 V MPPT window, leaving headroom even with long strings.
Peak efficiency reaches 98.4 %. The enclosure is IP66, cooling is by natural convection and the operating range spans -25 to +60 °C, so the unit mounts outdoors with no special measures.
Wi-Fi and LAN come as standard, together with RS485 for the export meter; 4G is optional. Monitoring and setup go through the Solplanet Cloud app, including export control and feed-in power limiting.
At a glance
Rated AC power3 kW
MPP trackers2, 150-1000 V
PV arrayup to 4500 Wp
Peak efficiency98.4 %
ProtectionIP66, -25 to +60 °C
Technical data
| Feature | Value |
|---|---|
| Manufacturer | Solplanet (AISWEI) |
| Model | ASW3K-LT-G2 Pro |
| Rated AC power | 3 kW |
| Max apparent power | 3 kVA |
| Max PV array power | 4500 Wp |
| Grid connection | 3/N/PE 230/400 V - 50/60 Hz |
| MPP trackers | 2 |
| String inputs | 2 |
| Max DC voltage | 1100 V |
| MPPT voltage range | 150 - 1000 V |
| Start-up voltage | 180 V |
| Max output current | 4,8 A |
| Max efficiency | 98.4 % |
| Cooling | Natural convection |
| Communication | Wi-Fi and LAN standard, RS485, optional 4G |
| Enclosure rating | IP66 |
| Operating temperature | -25 ... +60 °C |
| Dimensions | 503 x 435 x 183 mm |
| Weight | 16 kg |
Installation and commissioning must be carried out by qualified personnel, in line with local regulations and the manufacturer instructions.
