Deye GB-W 120.3 kWh LiFePO4 Indoor Battery System, 512 V 235 Ah High Voltage
Deye GB-W 120.3 kWh LiFePO4 Indoor Battery System, 512 V 235 Ah High Voltage
Regular price
€32,205.25
Regular price
Sale price
€32,205.25
Unit price
per
Tax included.
AVAILABILITY
3 units in stock at our supplier
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: €60 on orders up to €350, free shipping over €350.
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Prices shown include 22% Italian VAT. The 10% rate applies only to goods for photovoltaic and storage systems, with a declaration from the customer. From outside Italy: pick 22% VAT, or for 0% VAT place the order by bank transfer without paying and we will send a proforma invoice.
How VAT works ›
How VAT works ›
Delivery in 10-20 daysDeye
Deye GB-W 120.3 kWh LiFePO4 Indoor Battery System, 512 V 235 Ah High Voltage
Ten 12.03 kWh modules stacked in a column, 512 V nominal and 120.3 kWh on the nameplate, of which 108.2 kWh usable at 90% depth of discharge. This is the size that fits a workshop, a hotel, a mid-sized retail unit: enough energy to shift a full day of consumption without going to container scale.
Nominal charge and discharge power in this configuration is 117.7 kW, with 230 A continuous and peaks up to 322 A for one second: the system takes motor inrush without tripping into protection. Cooling is natural air, so there is no chiller to maintain, and communication runs over CAN and RS485 to hybrid inverters from 30 to 125 kW.
The GB-W range is rated for at least 6,000 cycles at 25 °C with 0.5 C discharge and 70% end-of-life capacity: on daily cycling that is more than sixteen years. Installation is indoor, with built-in fire protection. Capacity can be configured from 60.1 to 192.5 kWh by changing the number of modules, so the same architecture still works if your needs change. 10-year warranty.
At a glance
Nominal energy: 120,3 kWhDeye is one of the largest inverter and storage manufacturers in the world: its commercial and industrial line is built on the same electronics as its residential hybrids, scaled up to tens or hundreds of kWh.
Usable energy: 108.2 kWh (90% DoD)Deye is one of the largest inverter and storage manufacturers in the world: its commercial and industrial line is built on the same electronics as its residential hybrids, scaled up to tens or hundreds of kWh.
Nominal system voltage: 512 VDeye is one of the largest inverter and storage manufacturers in the world: its commercial and industrial line is built on the same electronics as its residential hybrids, scaled up to tens or hundreds of kWh.
Operating voltage range: 416 – 584 VDeye is one of the largest inverter and storage manufacturers in the world: its commercial and industrial line is built on the same electronics as its residential hybrids, scaled up to tens or hundreds of kWh.
Modules in series: 10 (configurable from 5 to 16)Deye is one of the largest inverter and storage manufacturers in the world: its commercial and industrial line is built on the same electronics as its residential hybrids, scaled up to tens or hundreds of kWh.
Technical data
| Specification | Value |
|---|---|
| Nominal energy | 120,3 kWh |
| Usable energy | 108.2 kWh (90% DoD) |
| Nominal system voltage | 512 V |
| Operating voltage range | 416 – 584 V |
| Modules in series | 10 (configurable from 5 to 16) |
| Single module | 12.03 kWh — 235 Ah — 51.2 V |
| Cell chemistry | LiFePO4 |
| Nominal charge/discharge power | 117,7 kW |
| Max continuous current | 230 A (peak 322 A for 1 s) |
| Rated cycle life | ≥ 6,000 at 25 °C, 0.5 C, 70% end of life |
| Operating temperature | charge 0 – 55 °C, discharge −20 – 55 °C |
| Cooling | natural air |
| Communication | CAN, RS485 |
| Installation | indoor, with built-in fire protection |
| Compatible inverters | hybrids from 30 to 125 kW |
| Warranty | 10 years |
| Shipping | on a pallet with a specialised carrier, quoted case by case |
