• Victron Energy EasySolar-II 48/6k5/100-32 MPPT 250/100 GX inverter caricabatterie 48V 6500VA 100A
1 1

Victron Energy

Victron Energy EasySolar-II 48/6k5/100-32 MPPT 250/100 GX inverter charger 48V 6500VA 100A

Victron Energy EasySolar-II 48/6k5/100-32 MPPT 250/100 GX inverter charger 48V 6500VA 100A

€2,208.20
€2,208.20
Sale Sold out
Tax included.
Titolo
Delivery in 10-20 days5-year warrantyVictron Energy
Shipping costsItaly: free over €150; €13 for smaller orders.
European Union: free from €350; €60 for smaller orders.

Victron Energy EasySolar-II 48/6k5/100-32 MPPT 250/100 GX inverter charger 48V 6500VA 100A

The EasySolar-II 48/6k5/100-32 MPPT 250/100 GX puts a 6500 VA MultiPlus-II, a SmartSolar MPPT 250 V / 100 A charge controller and a GX device with display into one unit: a home storage system already assembled, ready to connect to the grid and to the PV array. A 100 A charger and a 32 A transfer switch.

Key strengths

Two independent AC outputs
The second output is live only when grid or generator is present: it separates critical loads from non-priority ones.
PowerControl
Automatically limits the current drawn from the grid or generator so they are never overloaded: loads come first, battery charging uses whatever is left.
PowerAssist
Adds inverter power to the grid or generator to cover consumption peaks. A 16 A socket can then run far more demanding loads.
UPS function
During a blackout the changeover takes under 20 milliseconds: computers, servers and sensitive equipment keep running without noticing.
4-stage adaptive charging
The adaptive algorithm (bulk, absorption, float, storage) and BatterySafe mode extend lead-acid battery life and are fully compatible with LiFePO4 lithium.

Monitoring and configuration

The GX device is already built in: no separate Cerbo GX is needed. System monitoring is available straight away, locally and remotely on the free VRM portal, with data history, alarms and remote firmware updates.

Technical specifications

FeatureValue
Victron part numberPMP482657010
Battery voltage48 V
Inverter power (25 °C)6500 VA / 5200 W
Charge current100 A
AC transfer current32 A
AC output230 V ± 2% – 50 Hz
Changeover (UPS)< 20 ms
Built-in solar charge controller250 V / 100 A
Built-in GX deviceYes
CommunicationVE.Bus
Parallel / three-phaseYes, up to 6 units
Protection ratingIP21
Dimensions (H × W × D)670 × 320 × 270 mm
Weight40 kg
Warranty5 years

Downloadable documentation

PDFEasySolar-II GX datasheetOfficial Victron Energy document · download as PDF
View full details
