SolarEdge IAC-RBAT-5KCBAT-01 Module-to-Module Cable Kit for Home Battery 48V
SolarEdge IAC-RBAT-5KCBAT-01 Module-to-Module Cable Kit for Home Battery 48V
Regular price
€74.24
Regular price
Sale price
€74.24
Unit price
per
Prices exclude VAT: tax is calculated in the cart based on the delivery country.
EU businesses: enter your VAT number at checkout.
AVAILABILITY
Product available, quantity not tracked
Shipping
- Italy: €13 on orders up to €150, free shipping over €150.
- European Union: 60 € per order, with no threshold
Rates apply to the cart total and are confirmed at checkout, where shipping to countries outside the EU is also calculated.
Couldn't load pickup availability
Delivery in 10-20 daysAccessoryLow voltageSolarEdge
SolarEdge IAC-RBAT-5KCBAT-01 Module-to-Module Cable Kit for Home Battery 48V
The SolarEdge IAC-RBAT-5KCBAT-01 cable kit is the original interconnection set between two SolarEdge Home Battery 48V (BAT-05K48) battery modules installed in the same tower. It contains the positive and negative DC cables, the earthing cable and the communication cable, with pre-assembled SolarEdge connectors, and is used to connect the modules in parallel in order to increase the available energy.
In the low voltage SolarEdge Home system, up to 4 modules per tower can be stacked and up to 5 modules per inverter connected, for a maximum of approximately 23 kWh. One module-to-module kit is required for each additional module beyond the first within the same tower; to connect two separate towers the IAC-RBAT-5KCTOW-01 kit is used instead. The batteries communicate with each other over RS485 and with the inverter over the CAN bus.
Key features
Module-to-module interconnectionConnects two Home Battery 48V modules in parallel within the same tower.
Complete setPositive and negative DC cables, earthing cable and communication cable with original connectors.
Pre-assembledSolarEdge connectors already fitted for fast and safe installation.
Short cablesReduced lengths, designed for stacked and adjacent modules (package 190 x 195 x 40 mm).
System expansionRequired for each additional module: up to 4 modules per tower and 5 per inverter.
RS485 communicationCarries the RS485 data link between the module BMS units.
Technical specifications
| Feature | Value |
|---|---|
| Product code | IAC-RBAT-5KCBAT-01 |
| Model | IAC-RBAT-5KCBAT-01 |
| Function | Interconnection cable kit between battery modules in the same tower |
| Compatibility | SolarEdge Home Battery 48V (BAT-05K48) |
| Storage system | SolarEdge Home Battery 48V, low voltage, 4.6 kWh usable per module |
| Contents | Positive and negative DC cables, earth cable, communication cable |
| System voltage | 44.8-56.5 Vdc |
| Communication | RS485 between battery modules |
| Required quantity | 1 kit for each additional module in the same tower |
| Modules per tower | Maximum 4 modules per tower, 5 modules per inverter (approx. 23 kWh) |
| Protection rating | Watertight connectors; the battery module is IP65 / NEMA 3R |
| Packaging dimensions | 190 x 195 x 40 mm |
| Weight | Approx. 0.84 kg |
| Warranty | Not declared in the datasheet |
Documentation
PDFDatasheet IAC-RBAT-5KCBAT-01Official manufacturer documentPlease check compatibility with your storage system before ordering.
