Hoymiles 14.16 kWp Solar Kit – 12 kW Three-Phase Hybrid Inverter, Commercial/Industrial
Hoymiles 14.16 kWp Solar Kit – 12 kW Three-Phase Hybrid Inverter, Commercial/Industrial
Regular price
€6,192.54
Regular price
Sale price
€6,192.54
Unit price
per
Tax included.
Couldn't load pickup availability
VAT note
Businesses and private customers outside Italy: purchase with 22% VAT. The 10% VAT rate is reserved for private customers resident in Italy — learn more.
Foreign businesses entitled to 0% VAT: write to info@litio.store.
Businesses and private customers outside Italy: purchase with 22% VAT. The 10% VAT rate is reserved for private customers resident in Italy — learn more.
Foreign businesses entitled to 0% VAT: write to info@litio.store.
Shipping costs
Italy: €120.European Union: €350.
Italy: €120.European Union: €350.
Hoymiles 14.16 kWp Solar Kit – 12 kW Three-Phase Hybrid Inverter, Commercial/Industrial
Scalable solution for commercial and industrial sites, built to maximise self-consumption
🚚 Delivery in 10–20 days for modules and inverter; the AC (with CEI 0-21 interface protection) and DC protection panels have a 3–4 month lead time.
Commercial & Industrial Solar Kit
Three-phase hybrid PV system for grid-connected operation with energy management, designed around the Hoymiles HYT-12000HV inverter, for medium-sized businesses.
| ☀️ 14.16 kWp Solar | ⚡ PV Only No Storage | ⚡ 12 kW Inverter | 🔌 Three-Phase Hybrid |
Kit Contents
24× 590 W N-Type TOPCon bifacial double-glass Silver Frame modules
for a total output of 14.16 kWp.
1× Hoymiles HYT-12000HV 12kW 12000W Three-Phase
1× Three-phase PV AC panel 15 kW 25 A with CEI 0-21 SPI and SPD, IP65
Protection and isolation of the AC grid connection.
1× PV DC panel 2 strings 2 MPPT 900 V 14–20 A with MCBs and SPD, IP65
Protection and isolation of the PV strings on the DC side.
PV String Design
Calculated configuration: 2 strings of 12 modules, one per MPPT. Operating voltage Vmp 532.2 V, Voc at 25 °C 633.8 V, conservative Voc at −25 °C 723 V — within the inverter’s 1000 V limit and within the 200–950 V MPPT window. Maximum current per MPPT 13.3 A. Module used: 590 W N-Type TOPCon bifacial double-glass module (Vmp 44.35 V, Voc 52.82 V, Imp 13.30 A; conservative coefficient −0.28 %/°C). DC/AC oversizing ratio: 1.18×. Preliminary configuration: to be re-checked against the datasheet of the revision actually purchased and the site conditions.
Storage, Grid and Operation
- ✓Grid-connected operation.
- ✓LiFePO₄ batteries not included in this configuration.
A consistent, well-engineered system
The kit uses selected components and a PV configuration sized to the inverter’s electrical limits, for a robust, consistent commercial or industrial system ready for installation by qualified personnel. The kit includes only the specified PV panels, inverter, and AC and DC protection panels. Mounting structures, cables, connectors and installation are not included and must be sized by the installer to suit the site. Installation and grid connection must be carried out by licensed personnel.
